Ericsson RNT447 37/01 for AAU Power Connector

Product Introduction – Ericsson RNT447 37/01 DC Power Connector for AAU / RRU

Overview

The Ericsson RNT447 37/01 is a high-performance DC power connector designed for Ericsson‘s cellular base station equipment, including RRU (Remote Radio Unit), BBU (Baseband Unit), and 5G AAU (Active Antenna Unit). This 2-pin circular bayonet lock connector is part of Ericsson’s RNT447 series power solution, providing reliable DC power transmission in outdoor macro cells, D-RAN, and 5G base station deployment scenarios. It is manufactured under the Amphenol Ericsson brand and is widely used as a replacement or original accessory for Ericsson‘s radio equipment power supply systems.

Key Features

1. High Current Capacity, Stable Power Supply

• Maximum current rating: 55A standard (up to 65A with upgraded contact material)

• Nominal voltage: -48V DC; operating voltage ≤ 60V DC

• Socket screw contact supports cables from 2.5 to 16 mm² (6–14 AWG), covering a wide range of power transmission needs

2. Durable Construction for Outdoor Use

• Zinc alloy shell construction provides EMI shielding and excellent shock & vibration resistance

• IP65 rated for outdoor use (IP67 when mated), ensuring reliable operation in harsh environmental conditions

• Wide operating temperature range: -40°C to +85°C, suitable for extreme climates from deserts to high-altitude cold regions

3. Easy Field Installation

• Screw termination contacts allow for simple, tool-assisted installation directly in the field without specialized equipment

• Bayonet lock connector design ensures secure mating with clear tactile feedback, preventing accidental disconnection

• Supports hot plug functionality for convenient maintenance and replacement

4. Strong Compatibility Across Ericsson Equipment

• Compatible with Ericsson RRU series: Radio 22xx series (e.g., Radio 2212, 2219), Radio 44xx series (e.g., Radio 4415, 4443), RRUS12 (commonly used in 4G/LTE base stations)

• Applicable to 5G AAU devices, including Air 6488 and similar models (please confirm specific compatibility with your equipment)

• Part of the RNT447 series, which also includes models such as 32/02, 31/03, 30/02, 38/02, and 39/01 for different power and application requirements

Technical Specifications

Application Scenarios

• Outdoor Macro Cell Base Stations: Connects RRU to -48V DC power supply for reliable outdoor operation

• Distributed RAN (D-RAN): Used for power transmission between BBU and RRU to ensure stable power supply

• 5G Base Station Deployment: Provides power connection for 5G AAU devices in high-density, high-power scenarios

• Base Station Maintenance and Upgrades: Ideal for replacing aging power connectors in existing Ericsson equipment

Purchasing Recommendations

• Confirm your equipment model: Verify that your RRU, AAU, or BBU is compatible with RNT447 series connectors before purchasing.

• Standard choice for 4G/LTE RRU: RNT447 37/01 is a reliable standard option for Radio 22xx, Radio 44xx, and RRUS12 series.

• For 5G AAU deployment: Suitable for Ericsson Air 6488 and similar 5G AAU devices (confirm compatibility with your specific model).

• Consider higher-current variants: For high-power applications, consider RNT447 38/02 or 39/01 models which offer enhanced thermal performance and current capacity.

• Not compatible with non-Ericsson equipment: This connector is specifically designed for Ericsson AAU/RRU equipment and may not fit other brands.

• All products are inspected for appearance and electrical performance before shipment.

For technical support or bulk orders, please contact us.

Its weight is approximately 190-220g.
